Self loading stacker
EMC
A8
| MAXIMUM LIFT HEIGHT | 800 mm. |
| Full length | 1600 mm. |
| WIDTH | 770 mm. |
| MAST HEIGHT WITH COLLECTED | 1200 mm. |
| MAXIMUM LOAD | 600 Kg. |
| MINIMUM HEIGHT FORK | 85 mm. |
| EXTERIOR FORK | 540 mm. |
| DISTANCE FROM THE CENTER OF GRAVITY LOAD | 500 mm. |
| ELECTRIC MOTOR | 12 V - 700 W. |
| BATTERY | 12 V - 75 Ah |
| BATTERY CHARGER | 12V. - 7 Ah |
| NO WHEELS | February |
| No. ROLLERS | 4 |
| TOTAL WEIGHT | 225 kg. |
This data sheet belongs to the next category:
High lift pallet trucks
